Spider Blocker Mount - Universal Mounting Kit for DIN Rails and Flat Panels
Date : Tuesday, 03 July 2018
Read More...Profile PCB Holders Mini - 42mm
Date : Thursday, 14 June 2018
Profile PCB Holders Mini
DIN Rail or Panel Mount
42mm Width PCB
Profile PCB Holders provides quick & easy mounting of PCBs on Din Rail & Wall / Panel. Profiles are available in standard 1 or 2 Meter length or it can be easily cut to required custom lengths. Profiles are also available with custom length from us with accurate cutting. The typical applications of Profile PCB Holders include Mounting custom PCB and Standard interface modules for Din Connectors, Sub Miniature Din Connectors, Flat Cable Connectors also Modules like Relay modules, Opto - coupler modules, Switch modules, Fuse modules, Diode modules, Veristor Modules, Power supply modules, Over Voltage protection modules, Data Transmission & Receiver Modules, Analog/ Digital Converter etc.
Features
- Din Rail mounting in EN 60 715 TH35 DIN rails.
- Panel / wall Mounting
- For 42 width PCB size.
- Available in standard 1 meter and 2 meter extrusion length.
- Available with custom length & in preassembled kit form to save time
Mounting of Profile PCB Holders:
DIN Rail Mounting: The Profile is mounted on DIN rail with help of End Piece with Rail mounting foot Left side and Right side; PCB slides into grooves on the extrusion. Two End Pieces are fixed with screws on extrusion to hold PCB securely in place and to keep out foreign objects.
Panel Mounting: To panel mount, Two Panel Mont End Pieces which has an integral mounting flange with hole slot. There is no need of Foot Pieces in Panel mounting.
Note: Save time by ordering Kit with our preassembled Profile Holders, made from profile extensions cut to size and two End Sections. They can be ordered for DIN rail or panel mounting for custom length.
Material :
Profile – Extrusion molded : PVC Self-extinguishing PVC - FR - UL94V-0
End Piece : Nylon 6.6 - FR - UL94V-2
Color : Green
Read More..."Pin It" Our Enclosures for your Engineering / Design source - Gaurang Enclosures on pinterest.com
Date : Monday, 23 February 2015
Now you can refer our Enclosures and components at www.pinterest.com/GaurangCases
You can see our different families of Enclosures and components in PINS having high resolution Images and Product detail in different BOARDS.
We request you to "Pin It" the PINS / Product OR Follow our BOARDS for your future reference at the time of Engineering / designing or making prototype. It is than readily available handy source.
Please Follow us or follow individual BORD of your liking to get new updates right on your screen.
We like to meet: Engineers, Manufacturers, OEM's, Stocking Distributors, Non-Stocking Distributors, Buyers, Custom Applications, and other interested parties.
Gaurang Enclosures
Read More...Euro Terminals in Din Panel Cases
Date : Thursday, 20 November 2014
Now Din Panel Cases are available with Euro Terminals. New Innovative designed Back Plate facilitate Din Panel Cases use of Euro Terminals on back side. Euro Terminals of 5mm / 5.08mm pitch provides more number of terminals. Standard commercial euro terminal provides wide choice in current rating, insulation and have all international approvals UL, CE…
Knock Out Blanks for Individual Terminal Configuration
New Innovative designed Back Plate is a closed one with Knock out blanks. The openings for Terminals in two rows top & bottom are achieved by knocking out blanks as per terminal configuration. This feature gives enclosure tailored made enclosure look and allows use of terminals only as per requirement without any wastage thereby saving in terminal cost.
Features:
- 24 (12+12) max. Plug-In Euro Terminals in 96 x 96 x 65mm, 96 x 96 x 110mm & 96 x 96 x 150mm cases
- 15 max. Fixed OR Plug-In Euro Terminals in 96 x 48 x 67mm, 96x 48x 110mm & 96 x 48 x 150mm cases
- Custom Configuration with Knockout blanks
- Wide choice in current rating, insulation available in Standard Euro terminal
- International approvals UL, CE.. of Standard Euro terminal
- Saving by using only required number of terminals.
- Terminals are optional – Cases supplied with / without terminals - customer can use standard commercial euro terminal available of their choice
Continuing Leadership with Innovative Design from GAURANG
Read More...Happy Twitterversary!
Date : Saturday, 16 August 2014
On 3rd Twitterversary! We thanks customers, friends, and staff. We promise to continue developing / supplying Innovative enclosures to electronic Industry.
Are you on Twitter? Follow us today! http://twitter.com/GAURANG_Cases
Your Plastic Enclosure and Components Specialist.
Gaurang Electronic Industries.
